TNPW12069K09BYTA

Image is for reference, please contact us to get the real picture

Part No :: TNPW12069K09BYTA

Manufacturer: Vishay / Dale

Description: RES 9.09K OHM 0.1% 1/4W 1206

Catalog: Chip Resistors-Surface Mount

Availability: 327332 pieces

Shipped from: HK warehouse

Expected Shipping Date: Sep 23 - Sep 27 2025

PDF: TNPW12069K09BYTA PDF

Type	Description
Series:	TNPW
Package:	Tape & Reel (TR)
Part Status:	Active
Resistance:	9.09 kOhms
Tolerance:	±0.1%
Power (Watts):	0.25W, 1/4W
Composition:	Thin Film
Features:	Military
Temperature Coefficient:	±10ppm/°C
Operating Temperature:	-55°C ~ 125°C
Package / Case:	1206 (3216 Metric)
Supplier Device Package:	1206
Ratings:	-
Size / Dimension:	0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max):	0.026" (0.65mm)
Number of Terminations:	2
Failure Rate:	-

TNPW12069K09BYTA is available at GangBo-ic.com, Please review product page below for detailed information, including TNPW12069K09BYTA price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for TNPW12069K09BYTA to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
