PAT0603E2940BST1

Image is for reference, please contact us to get the real picture

Part No :: PAT0603E2940BST1

Manufacturer: Vishay

Description: RES SMD 294 OHM 0.1% 0.15W 0603

Catalog: Chip Resistors-Surface Mount

Availability: 516951 pieces

Shipped from: HK warehouse

Expected Shipping Date: Sep 10 - Sep 14 2025

PDF: PAT0603E2940BST1 PDF

Type	Description
Series:	PAT
Package:	Tape & Reel (TR)
Part Status:	Active
Resistance:	294 Ohms
Tolerance:	±0.1%
Power (Watts):	0.15W
Composition:	Thin Film
Features:	Anti-Sulfur, Automotive AEC-Q200, Moisture Resistant
Temperature Coefficient:	±25ppm/°C
Operating Temperature:	-55°C ~ 155°C
Package / Case:	0603 (1608 Metric)
Supplier Device Package:	0603
Ratings:	AEC-Q200
Size / Dimension:	0.064" L x 0.032" W (1.63mm x 0.81mm)
Height - Seated (Max):	0.018" (0.46mm)
Number of Terminations:	2
Failure Rate:	-

PAT0603E2940BST1 is available at GangBo-ic.com, Please review product page below for detailed information, including PAT0603E2940BST1 price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for PAT0603E2940BST1 to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
