CONN HEADER SMD R/A 56POS 2MM
CONN RCPT 24POS 0.079 GOLD PCB
SQUARE FLANGE RECETACLE
JAM NUT RECEPTACLE
Image is for reference, please contact us to get the real picture
| Type | Description |
|---|---|
| Series: | DF11 |
| Package: | Bulk |
| Part Status: | Obsolete |
| Connector Type: | Receptacle |
| Contact Type: | Female Socket |
| Style: | Board to Board or Cable |
| Number of Positions: | 24 |
| Number of Positions Loaded: | All |
| Pitch - Mating: | 0.079" (2.00mm) |
| Number of Rows: | 2 |
| Row Spacing - Mating: | 0.079" (2.00mm) |
| Mounting Type: | Through Hole |
| Termination: | Press-Fit, Solder |
| Fastening Type: | Friction Lock |
| Contact Finish - Mating: | Gold |
| Contact Finish Thickness - Mating: | 8.00µin (0.203µm) |
| Insulation Color: | Black |
| Insulation Height: | 0.244" (6.20mm) |
| Contact Length - Post: | 0.118" (3.00mm) |
| Operating Temperature: | -30°C ~ 85°C |
| Material Flammability Rating: | UL94 V-0 |
| Contact Finish - Post: | Nickel |
| Mated Stacking Heights: | 7.8mm, 8.45mm |
| Ingress Protection: | - |
| Features: | - |
| Current Rating (Amps): | 2A |
| Voltage Rating: | 250V |
