536275-7

536275-7

Image is for reference, please contact us to get the real picture

Part No :

536275-7

Manufacturer
TE Connectivity AMP Connectors
Description
CONN HEADER VERT 40POS 1.27MM
Catalog
Rectangular Connectors - Headers, Male Pins
Availability
108410 pieces
Shipped from
HK warehouse
Expected Shipping Date
Oct 26 - Oct 30 2025
PDF
536275-7 PDF
Type Description
Series:Micro-Strip
Package:Tube
Part Status:Active
Connector Type:Plug
Contact Type:Male Pin
Pitch - Mating:0.050" (1.27mm)
Number of Positions:40
Number of Rows:2
Row Spacing - Mating:0.100" (2.54mm)
Number of Positions Loaded:All
Style:Board to Board
Shrouding:Shrouded - 4 Wall
Mounting Type:Through Hole
Termination:Press-Fit, Solder
Fastening Type:Push-Pull
Contact Length - Mating:-
Contact Length - Post:0.145" (3.68mm)
Overall Contact Length:-
Insulation Height:0.340" (8.64mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:30.0µin (0.76µm)
Contact Finish - Post:Tin-Lead
Contact Material:Phosphor Bronze
Insulation Material:Thermoplastic
Features:Ground Bus (Plane), Mounting Flange
Operating Temperature:-65°C ~ 125°C
Ingress Protection:-
Material Flammability Rating:-
Insulation Color:Natural
Current Rating (Amps):Varies by Wire Gauge
Voltage Rating:30VAC
536275-7 is available at GangBo-ic.com, Please review product page below for detailed information, including 536275-7 price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for 536275-7 to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
