CONN HEADER R/A 60POS 2.54MM
CONN HEADER VERT 34POS 1.27MM
CONN RCPT 9POS 0.1 GOLD PCB
8D 19C 19#12 PIN RECP
Type | Description |
---|---|
Series: | 2500 |
Package: | Bulk |
Part Status: | Obsolete |
Connector Type: | Header |
Contact Type: | Male Pin |
Pitch - Mating: | 0.100" (2.54mm) |
Number of Positions: | 60 |
Number of Rows: | 2 |
Row Spacing - Mating: | 0.100" (2.54mm) |
Number of Positions Loaded: | All |
Style: | Board to Board or Cable |
Shrouding: | Shrouded - 4 Wall |
Mounting Type: | Through Hole, Right Angle |
Termination: | Solder |
Fastening Type: | Push-Pull |
Contact Length - Mating: | 0.243" (6.17mm) |
Contact Length - Post: | 0.155" (3.94mm) |
Overall Contact Length: | - |
Insulation Height: | 0.338" (8.59mm) |
Contact Shape: | Square |
Contact Finish - Mating: | Gold |
Contact Finish Thickness - Mating: | 15.0µin (0.38µm) |
Contact Finish - Post: | Tin-Lead |
Contact Material: | Copper Alloy |
Insulation Material: | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled |
Features: | Keying Slot |
Operating Temperature: | -55°C ~ 105°C |
Ingress Protection: | - |
Material Flammability Rating: | UL94 V-0 |
Insulation Color: | Black |
Current Rating (Amps): | 1.75A |
Voltage Rating: | - |
