929648-02-36-EU

929648-02-36-EU

Image is for reference, please contact us to get the real picture

Part No :

929648-02-36-EU

Manufacturer
3M
Description
CONN HEADER R/A 36POS 2.54MM
Catalog
Rectangular Connectors - Headers, Male Pins
Availability
089708 pieces
Shipped from
HK warehouse
Expected Shipping Date
Oct 31 - Nov 04 2025
PDF
929648-02-36-EU PDF
Type Description
Series:929
Package:Bulk
Part Status:Obsolete
Connector Type:Header, Breakaway
Contact Type:Male Pin
Pitch - Mating:0.100" (2.54mm)
Number of Positions:36
Number of Rows:1
Row Spacing - Mating:-
Number of Positions Loaded:All
Style:Board to Board
Shrouding:Unshrouded
Mounting Type:Through Hole, Right Angle
Termination:Solder
Fastening Type:Push-Pull
Contact Length - Mating:0.235" (5.97mm)
Contact Length - Post:0.405" (10.29mm)
Overall Contact Length:-
Insulation Height:0.115" (2.92mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:10.0µin (0.25µm)
Contact Finish - Post:Gold
Contact Material:Copper Alloy
Insulation Material:Polycyclohexylenedimethylene Terephthalate (PCT)
Features:-
Operating Temperature:-40°C ~ 105°C
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Insulation Color:Black
Current Rating (Amps):2.5A
Voltage Rating:-
929648-02-36-EU is available at GangBo-ic.com, Please review product page below for detailed information, including 929648-02-36-EU price, datasheets, in-stock availability, technical difficulties. Quickly Enter the access of compare list to find replaceable electronic parts. Want to gain comprehensive data for 929648-02-36-EU to optimize the supply chain (include cross references, lifecycle, parametric, counterfeit risk, obsolescence management forecasts), please contact to our Tech-supports team.
